Dual Band Signal Booster Voice & 4G – 600 sq.m.

(Vodafone, 2Degrees & Warehouse Mobile)

  • Application:

    2 Band
  • Coverage:

    up to 600 sqm
  • Ideal For:

  • Provider:

  • Frequency:

    900/1800 MHz
  • Data:

    4G Data & Voice
Free Shipping In NZ Delivery time: 5-7 Business Days

Benefits and Features:

  • Instant Signal Boost of up to 5 bars
  • CE & RoHS ISO Certified Product
  • Easy Installation
  • Instant Technical Assistance
  • 3-Year Warranty Included

$ 720

Was $ 865. Save $ 145

Units Sold: 4261

Free Shipping

Overview

Kit includes:

  • 1x repeater
  • 1x indoor antenna
  • 1x outdoor Panel antenna
  • 1x power adapter
  • 1x 15 metres cable
  • 1x 5 metres cable

For better connection add an LPDA antenna to your order

If our standard package cable length is not enough to cover your area you have an upgrade option.
Upgrade your booster kit with our internal antenna for optimal performance in larger spaces.
Price Match Guarantee

If you have a problem with a poor outside signal, we are here to help. This device is designed to propel your connection up to 5 bars strength over 600 square metresmaking it perfect for a big home, office, bar or restaurant.

The installation and operation of this product are very simple. You or anyone from your family or office can set it up without hassle in no time. We make sure that you face no issues, by providing you with the full kit to install with free delivery. If you have any issues with the device, we are here to help with our 24/7 support.

This booster is health hazard-free and comes with a 2-year warranty, as well as a 30-day money-back guarantee.

  • Technical Sheet
  • Coverage
    up to 600 sqm
  • Use
    Medium Home
    Medium Office
  • Operator
    Vodafone (2G, 3G, 4G)
    2Degrees (2G, 3G, 4G)
    Warehouse Mobile (2G, 3G, 4G)
  • Frequency
    900/1800 MHz
  • Number of simultaneous users
    75
  • Up-link
    890 ~ 915 MHz
    1710 ~ 1785 MHz
  • Down-link
    935~ 960 MHz
    1805 ~ 1880 MHz
  • Voltage
    AC:90~265V, 50/ 60Hz;DC:5V/ 4A
  • Dimensions
    198x138x30 mm.
  • Weight
    1.1 kg
  • Max Gain
    70 dB
  • output
    Up link :23dBm Downlink: 27dBm
  • Ripple in Band
    ≤5dB
  • Noise figure
    ≤6dB
  • Return Loss
    ≤-8 dB
  • Auto Level Control
    ≥20dBm
  • MGC
    31db@1dB/step
  • Time Delay
    ≤0.5 μs
  • Power Consumption
    ≤20W
  • Impedence
    50 Ω
  • RF Connector
    N -Female
  • Installation Type
    Wall Installation
  • Environment Conditions
    IP40
  • Cooling
    Heat sink Convection cooling
  • Humidity
    <90%
  • MTBF
    > 50000 hours
  • Ambient temperature
    -15°C ~ 55°C
  • I/O impedance
    50Ω/N connector
  • Transmission delay
    ≤0.5μs
  • LED
    • Band 1 UL/P
      If the light is light then there are no phone calls in the coverage area or cell phone does not contact BTS.
    • Band 2 UL/P
      If the light is red then there is a phone call in the coverage area, or cell phone contacts BTS periodically
    • Band 3 UL/P
      The constant RED light indicates System Warning. The repeater works in abnormal state or is self -oscillating.
  • LED
    • Band 1 DL/P
      If the light is dark then the amplified signal output power does not reach lighting threshold. Output power is ≤ 10dBm. This means the repeater works at small power output state
    • Band 2 DL/P
      The green light means that the amplified signal output power reaches lighting threshold. The repeater works in good amplification state. The repeater works in good amplification state.
    • Band 3 DL/P
      Red or Orange light means that the repeater works in best amplification state, output power reaches maximum
